CASTROL LubeCon Series 525 Lubricant

Description

Castrol LubeCon Series 525 is a synthetic, high temperature chain oil formulated with premium base fluids and

select additives for the most demanding high temperature chain applications in the industry. It provides a unique

and unsurpassed combination of extremely low volatility and low residue formation tendencies that allow for

reduced lubricant consumption. LubeCon Series 525 High Temperature Chain Oil is manufactured from a blend of

esters and synthetic fluids selected for their favorable volatility characteristics as well as their physical and

chemical stability at high temperatures with extremely low residue forming tendencies. LubeCon Series 525

lubricant can support fluid film lubrication on chain pins over a broad high temperature range. The lubricant

contains anti-wear additives for additional protection in boundary lubrication from surging loads and extreme

temperatures. LubeCon Series 525 lubricant contains inhibitors against corrosion and oxidation.

Application

LubeCon Series 525 High Temperature Chain Oil is designed and most effective for chain operating temperature

applications between 350°F/175°C, the point at which synthetics become cost effective, and 575°F/330°C.

LubeCon Series 525 maintains peak performance over the entire temperature range. With more frequent

relubrication, LubeCon Series 525 continues to perform at temperatures beyond 575°F/330°C. LubeCon Series

525 lubricant is designed for the lubrication of roller chains, slides, cams and general lubrication where a high

temperature synthetic lubricant is needed. Major applications include industries using high temperature convey or

systems used for baking, coating, drying and curing. Product application may be achieved by dip, spray, splash

and automatic dispensing equipment. Use of LubeCon automatic lubrication system is recommended to provide

the most benefit from the use of LubeCon Series 525.

Advantages

Application rate and frequency can be minimized due to extremely low volatility. Lubricant consumption is

minimized. Minimal residue forming tendency and cleansing action virtually eliminates shutdowns for periodic

cleaning of equipment. Dissolves and facilitates removal of pre-existing gum, varnish and carbonaceous residue.

Dripping and blow-off are minimized by reduced lubricant application requirements. Excellent fluid film and antiwear properties result in extended chain life and potential for energy reduction. Fire and explosion possibilities are

minimized due to extremely low volatility improving Safety and Environmental conditions. Overall cost reduction is

accomplished by extended lubrication cycles, reduced contamination, decreased downtime for maintenance and

repair, and longer parts life
