Description
Castrol Tribol 1066 Way Oil is a high performance slide and way lubricant. Tribol 1066 Way Oil was developed
specifically to lubricate the slides and ways of modern metalworking machine tools used in high precision, high volume
manufacturing.
Demands for increased production have led to the design of higher and higher speed machines. Increased operating
speeds have also spawned new metal removal fluids and coolants which are highly surface active to increase the speed
of tool wetting and the removal of heat.
The surfactant additives used in these modern coolants have a detergent and cleansing action on oil and can rapidly
displace lubricants used to protect slides and ways.
Tribol 1066 Way Oil is manufactured with the highest quality base oils and additives available. The base oils are highly
refined paraffinic base stocks with high Vis. They were selected for their ability to sustain a lubricating film despite
sudden changes in load or shearing forces. The formulation includes select polymer additives for both adhesive and
cohesive characteristics.
A carefully balanced treat rate of rust and oxidation inhibitors offers maximum rust protection for parts and long service
life from the oil. Tribol 1066 Way Oil is not corrosive to ferrous or nonferrous metals.
Application
Tribol 1066 Way Oil was developed primarily to lubricate modern machine tools. The special formulation of Tribol 1066
Way Oil resists the cleansing action of surface-active coolants so that wear on the slides and ways is minimized and
motion is smooth and accurate. Interaction between the metalworking fluid and slideway lubricant can result in lower
metalworking fluid performance and reduced fluid life. Tribol 1066 Way Oil was specifically developed to be nonemulsifying with water, synthetic and semi-synthetic metal removal fluids. It rapidly pops out of these fluids as free
tramp oil without removal of the fluid’s additives. This is achieved without the use of demulsifiers or surfactants that can
affect the stability of the coolants. This permits servicing of the metal removal fluids using conventional weiring or
skimming techniques. With the Tribol 1066 Way Oil, positive lubrication can be achieved to control wear and promote
machining accuracy without excessive reapplication or high lubricant consumption.
Advantages
• Tribol 1066 Way Oil effectively controls "stick-slip," resulting in higher quality output, fewer rejects and reduced
operating costs.
• Tribol 1066 Way Oil is compatible with both metal and plastic materials used on modern machining equipment.
• Outstanding demulsification properties with quality aqueous cutting fluids prolongs coolant life for additional cost
savings
