CASTROL OPTIGEAR SYNTHETIC 800/1000

Description

Castrol Optigear Synthetic™ 800 Range (previously called Tribol™ 800) synthetic gear oils have been developed for the

lubrication of heavily loaded gears, bushings and bearings which may operate over a broad range of temperatures from

ambient to elevated temperatures (>80°C/176°F). They are particularly intended to extend the service life of both lubricant

and machine parts where unusually high operating and oil reservoir temperatures are encountered. The high

performance characteristics of Optigear Synthetic 800 are achieved with select polyalkyleneglycol (PAG) based synthetic

fluids. They feature chemical and thermal stability, high viscosity index, water solubility, and compatibility with metals and

elastomers most commonly used in machine construction. The naturally high resistance to oxidation of the synthetic

base fluid is further enhanced by inhibitors. Corrosion protection is very effective even in the presence of water. Also, a

package of high performance additives acts in combination for superior anti-wear and Extreme Pressure (EP)

performance.

Application

-The Optigear Synthetic 800 range is especially suited to reservoirs and circulation systems operating at high

temperatures because of heat generated in severe service or high temperatures in the application. Optigear Synthetic

800 are intended for all types of heavily loaded gears including spur, bevel and worm gears. Although well suited for all

types of gearing and bearings, the Optigear Synthetic 800 range is particularly effective in controlling wear and reducing

friction between sliding surfaces. In addition, they possess a high degree of affinity for cupric metal alloys.

Advantages

-Shear stability - the synthetic base offers high viscosity index (VI) without the addition of VI improvers. In service,

VI improvers can shear, lowering oil viscosity and reducing protection critical for gear sets and bearings. The

naturally high VI of Castrol Optigear Synthetic 800 assures full protection for components over a wide range of

operating temperatures, speeds, and load conditions.

-Long life, extended drain intervals are possible because of the natural aging and oxidation resistance of the

synthetic base fluid. Advanced Castrol Optigear Synthetic lubrication technology forms friction-fighting, anti-wear

films that can significantly reduce local operating temperatures as gear teeth or bearing surfaces come into

contact.

-More protection for components in severe service. The extended EP performance of Optigear Synthetic 800 offers

protection beyond the capabilities of conventional petroleum oils.

-Wear protection under conditions of extreme temperature fluctuation and high loads. High efficiency and lower oil

temperature, especially in worm gear units.

-High corrosion protection of cast and steel surfaces through special additive packages, even in the presence of

water.

-Compatibility with non-ferrous metals through well-formulated synergistic additives.

-Potential energy savings as a result of a lower coefficient of friction.

-Reduction of maintenance costs as a result of significantly increased life of the lubricant.

Additional Information

-Optigear Synthetic 800 synthetic gear oils are water soluble, so spills may be cleaned up with water. They are NOT

compatible with mineral (petroleum) based lubricants. Condensation water may be absorbed without the damage of

corrosion or a change in viscosity. Cleaning lubrication systems with a flushing oil or Optigear Synthetic 800 prior to the

first filling is recommended. To achieve long drain cycles and obtain the economic advantages, systems must be free of

contaminants. The Optigear Synthetic 800 range is compatible with most seals including Viton A and nitrile or Buna N

(NBR). 800’s are NOT compatible with neoprene (polychloroprene) and butadiene seals - mixed polymers,

stryenebutadienes, polystyrene, or methacrylates.

This product was previously called Tribol 800 Range. The name was changed in 2015.
