Description
Castrol Tribol CH™ 1430 Spray (previously called Tribol 1430 Spray) high-temperature chain oil is a lubricant formulated
from aromatic ester for the lubrication of oven chains. The low evaporation tendency of the high-quality synthetic base
fluid ensures extended lubrication intervals as well as a clean and economic application.
The viscosity of Tribol CH 1430 Spray provides for excellent wetting of chain pins at temperatures upto 240°C with short
term maximum temperature of 270 °C. The product contains anti-wear additives for additional protection in the areas of
boundary and mixed friction and at high operating temperatures.
Rust and oxidation inhibitors protect chains from corrosion at standstill and extend the lubricant's life.
The Propellent used in Tribol CH 1430 Spray is a Propane/Butane mix. (Once evaporated it leaves Tribol CH 1430).
Application
Tribol 1430 high-temperature chain oil is especially recommended for chain lubrication at temperatures upto
240 °C with short term maximum temperature of 270 °C .
It is used for the lubrication of oven chains in lithographic printing plants and in the coating industry as well as in
drying ovens of the automotive industry
Advantages
The good evaporation characteristics of Tribol 1430 Spray can often reduce the lubricant amount to be applied
and/or extend the interval between reapplication
Reduced applications minimize soiling due to dripping or "blow-off"
Excellent fluid film and anti-wear properties control chain wear
Self-cleaning action all but eliminates the need to stop production to periodically clean some equipment
Tribol 1430 Spray also tends to dissolve and facilitate the removal of carbonaceous residues left by previous
lubricants
Fire and explosion hazards are greatly reduced. The ignition temperature far exceeds that of petroleum products
Low residue forming properties - any residues formed are still fluid and have lubricating properties
Compatible with the following sealing materials: Fluoroelastomers, silicone rubber, nitrile rubber (with more than
30%, acrylonitrile) and EPDM-elastomers
Excellent wetting and adhesive properties
Cost reductions may be achieved by reduced friction, extended lubrication cycles, reduced soiling, decreased
downtime for repairs and maintenance and longer service life of machine components
Additional Information
Do not use Tribol CH 1430 Spray high-temperature chain oil with seals under made of chloroprene rubber.
