CASTROL BRAYCOTE 601EF

Description

Castrol Braycote 601 EF is a smooth, buttery, translucent, off-white, NLGI #2 grease. Its base oil (Castrol Brayco® 815Z)

is a perfluorinated polyether, with exceptional chemical resistance, extremely low volatility, and a wide temperature

service range. The grease is non-toxic, nonflammable, and does not use any chlorofluorocarbons (CFC's) during

product manufacture. This product exhibits unusually high load-carrying capabilities as measured by the Four-Ball EP

Test, and contains a rust and corrosion inhibitor for extra component protection. Castrol Fluoroclean™ X100 or Castrol

Fluoroclean™ HE can be used to remove this lubricant. Refer to the data sheets for these products for information

regarding these products.

Application

Braycote 601 EF is designed to operate in the presence of rocket fuels and oxidizers and high vacuum. It is frequently

used in space applications including the Space Shuttle and satellites. It should also be considered in any application

where a hostile chemical or extreme environmental conditions would preclude the use of an ordinary grease. Typical

applications include ball and roller bearings, gears, and as an assembly lubricant for O-rings and elastomers.

Perfluorinated greases, such as this product, exhibit excellent shelf life due to their intrinsic inertness.

Additional Information

Temperature Range -80ºC to 204ºC (-112ºF to 400ºF) Limitations Braycote 601 EF is compatible with most commonly

utilized materials, plastics, and elastomers. It may be adversely affected by Lewis Acid Catalysts such as aluminum

chloride, at elevated temperatures. Newly exposed rubbing surfaces of aluminum, magnesium and titanium alloys may

react with this product under certain conditions. Such systems should be thoroughly evaluated. Surfaces must be well

cleaned of organic rust inhibitors prior to grease application to insure proper lubrication. This product is not

recommended for use in applications under high vacuum with loads exceeding 100,000 psi for extended periods of

time. Packaging Braycote 601 EF is available in 2 oz and 4 oz (AVDP) disposable polypropylene syringes, 1 lb jars, and

1.75 lb cartridges. A specially prepared "micronic", ultra clean version is available upon request. Approved to - Astrium

MPS0051
