Mobile ATF 220
Mobil ATF 220 is a high performance oil used in automatic transmissions of vehicles that want to use Dexron IID. It is also used as hydraulic fluid in special applications.
Features and Benefits
Mobil ATF 220 is formulated by combining high quality conventional base oils with a special additive system containing viscosity index enhancers, oxidation and antifoams that provide regular and controlled friction / wear properties. This product provides customers with excellent driving opportunities even in different driving conditions with various types of cars of 1994 and before. The main benefits are:
Features Advantages and Benefits
Good thermal and oxidation stability It counteracts the formation of lacquer, mud and sediment to keep the transmissions clean so that the oil will work effectively throughout its life.
Good anti-wear properties Meets the amount of wear that is accepted to provide longer transmission life
Excellent fluidity at low temperatures Facilitates first work and provides clean and fast lubrication at low temperatures
Effective foam control features Gives smooth and secure shifting under harsh operating conditions and reduces oil losses.
Compatible with all felt materials used for Type IID Provides effective seal control
Usage places
Mobil ATF 220 is recommended for automatic steering and automatic transmissions of passenger cars and light trucks, where the Dexron IID performance level is specified, as well as hydraulic steering systems in this context. It is also suitable for use in some special hydraulic systems of agricultural equipment and other systems where similar oil demands are made. It is recommended that the user is based on the manufacturer's instructions. The main areas of use are:
Transmissions, power steering and other hydraulic systems of vehicles working in the field conditions where Dexron IID or Allison C-4 type oils are desired to be used
Industrial hydraulic systems and parts
Specifications and Approvals
Mobil ATF 220 has the following builder approvals:
MB-Approval 236.7 X
MAN 339 TYPE D X
Voith DIWA G607 X
ZF TE-ML-03D / 04D / 11A / 14A / 17C X
Mobil ATF 220 is recommended for applications that require the following demands:
GM Dexron II X
Allison C-4 X
Color Doromat X
Caterpillar TO-2 X
Ford M2C163-A X
GM Type A Suffix A X
Typical Properties
Mobile ATF 220
Viscosity, ASTM D 445
cSt @ 40ºC 37
cSt @ 100ºC 7.0
Brookfield Viscosity, ASTM D 5293 -cP @ -40ºC 33,000
Viscosity Index, ASTM D 2270 153
Pour Point, ºC, ASTM D 97 -44
Flash Point, ºC, ASTM D 92 200
Density @ 15ºC kg / l, ASTM D 4052 0.870
Color Red
Health and Safety
In the light of current information; This product is not expected to have a negative impact on human health when used in the intended locations and following the recommendations provided in the Safety Data Sheet (MSDS). MSDS's are available upon request from the main distributor or via the Internet. This product should not be used for its intended purpose. When disposing of used products, be careful about environmental protection.
